Industries:
This makes it the perfect tool for the many jobs and challenges facing building fitters, as well as in plant and container construction, foundries and fettling shops, boiler and tank construction, structural steel engineering, pipeline construction, landscaping and installation.

Machine suitability:
The KSM cutting disc is suitable for freehand use on angle grinders as well as high-frequency (HF) machines and air grinders in any performance class.

Material suitability:
The KSM has been designed especially for use on steel (carbon steel – also termed structural steel, St37, S235JR and 1.0037) and cast steels.

Structure and production:
The cutting disc contains high-quality corundum (aluminium oxide) and 2 full-coverage glass cloth layers. The minimum side load for the cutting disc as defined by EN 12413 and oSa is 40 N (50 N from a diameter of 150 mm). The expiry date (three years) is embossed in the disc hole ring. Consistently high quality is ensured by sophisticated in-process controls applied during manufacturing. To ensure a maximum level of safety, every thousandth disc is tested destructively. This disc features a straight shape (shape 41). Cutting discs with a straight shape enable deeper insertion depths and therefore a greater number of cuts.

Applications:
The KSM offers an impressively aggressive cut during use, combined with smooth, vibration-free operation. This cutting disc helps to make work especially cost-effective. This quality RHODIUS tool is an especially good choice for cutting structural steel, supports, sections, panels and beams.

Dimensions:
The freehand cutting disc has a disc width of 3.0 mm and is available in diameters from 115 mm to 230 mm.
