Erwin Halder KG

Kolutno ročno kolo

light metal

Koda: EH 24600-1

Izberi izvedbo

Erwin Halder KG

Kolutno ročno kolo

light metal

Koda:: EH 24600-1

There are gripping indentations on the rear sides.

For all handwheels, the hub is machined, rim is turned and mirror-finished on all sides. The unmachined raw surfaces have been blasted clean. Together with their mirror-polished rim, these handwheels therefore present a finish which generally does not require additional lacquering.

Material

Axle part

Steel, zinc-plated by galvanization

Handwheel

Aluminium permanent-mould casting

Assembly

Shaft-end washers EH 22270. for axial fastening.

Za ogled cen se prijavite

Številka izdelka	B	b₃	d₁	d₂ [H7]	d₃	Axle part	Conflict Minerals free
EH 24600.0000	13 mm		80 mm	10 mm	26 mm	Steel, zinc-plated by galvanization	yes
Podatki se nalagajo...
EH 24600.0001	13 mm		80 mm	12 mm	26 mm	Steel, zinc-plated by galvanization	yes
Podatki se nalagajo...
EH 24600.0005	14 mm		100 mm	10 mm	28 mm	Steel, zinc-plated by galvanization	yes
Podatki se nalagajo...
EH 24600.0006	14 mm		100 mm	12 mm	28 mm	Steel, zinc-plated by galvanization	yes
Podatki se nalagajo...
EH 24600.0010	15 mm		125 mm	12 mm	31 mm	Steel, zinc-plated by galvanization	yes
Podatki se nalagajo...
EH 24600.0011	15 mm		125 mm	14 mm	31 mm	Steel, zinc-plated by galvanization	yes
Podatki se nalagajo...
EH 24600.0015	16.5 mm		140 mm	14 mm	36 mm	Steel, zinc-plated by galvanization	yes
Podatki se nalagajo...
EH 24600.0016	16.5 mm		140 mm	16 mm	36 mm	Steel, zinc-plated by galvanization	yes
Podatki se nalagajo...
EH 24600.0020	18 mm		160 mm	14 mm	36 mm	Steel, zinc-plated by galvanization	yes
Podatki se nalagajo...
EH 24600.0021	18 mm		160 mm	16 mm	36 mm	Steel, zinc-plated by galvanization	yes
Podatki se nalagajo...
EH 24600.0030	20.5 mm		200 mm	18 mm	42 mm	Steel, zinc-plated by galvanization	yes
Podatki se nalagajo...
EH 24600.0031	20.5 mm		200 mm	20 mm	42 mm	Steel, zinc-plated by galvanization	yes
Podatki se nalagajo...
EH 24600.0040	23 mm		250 mm	22 mm	48 mm	Steel, zinc-plated by galvanization	yes
Podatki se nalagajo...
EH 24600.0041	23 mm		250 mm	26 mm	48 mm	Steel, zinc-plated by galvanization	yes
Podatki se nalagajo...
EH 24600.0100	13 mm	3 mm	80 mm	10 mm		Steel, zinc-plated by galvanization	yes
Podatki se nalagajo...
EH 24600.0101	13 mm	4 mm	80 mm	12 mm		Steel, zinc-plated by galvanization	yes
Podatki se nalagajo...
EH 24600.0105	14 mm	3 mm	100 mm	10 mm		Steel, zinc-plated by galvanization	yes
Podatki se nalagajo...
EH 24600.0106	14 mm	4 mm	100 mm	12 mm		Steel, zinc-plated by galvanization	yes
Podatki se nalagajo...
EH 24600.0110	15 mm	4 mm	125 mm	12 mm		Steel, zinc-plated by galvanization	yes
Podatki se nalagajo...
EH 24600.0111	15 mm	5 mm	125 mm	14 mm		Steel, zinc-plated by galvanization	yes
Podatki se nalagajo...
